TELEMECANIQUE XPSAT5110 Safety Relay

Starting at €500.00 €500.00

Manufacturer's Suggested Retail Price (11-2014): €450.00
Product condition Availability Warranty
Price
Refurbished
Ships from: FRANCE Warehouse
stock available Immediate shipment Estimate my delivery
1 month Warranty - Factory return he product is under warranty for a factory return to our workshop, to be repaired or replaced, throughout its warranty period.
€500.00 €500.00
Your savings on Manufacturer's suggested retail price: -€50.00
Estimate Totals

Enter your destination to get a totals estimate.

  • Top-quality products backed by a warranty
  • Advanced technical support
  • Secure payment process with PDF invoice

Buy online your TELEMECANIQUE XPSAT5110 Safety Relay reference XPSAT5110 from our e-store Cnc-shopping, specialist in CNC machine-tools spare parts.

This Schneider Electric TELEMECANIQUE safety module from the PREVENTA XPS-AT family is used to supervise emergency stop circuits, guard switches and light-curtain outputs in CNC and industrial control panels. It provides safety-rated outputs to contactors and drive enables, making it a dependable replacement unit and CNC replacement component for maintenance teams and retrofit projects.

The unit serves as the safety interface between field devices and power switching elements. In typical CNC cabinets it links E-stop pushbuttons, door interlocks or presence sensors to the main contactor and the drive enable chain, helping ensure a verified stop before power is re-applied. The compact format suits crowded machine-tool enclosures where clear terminal identification and quick wiring checks matter.

Flexible power input accepts 24 VAC or 24 VDC, which simplifies field replacement without reworking the cabinet supply. This is particularly useful during unplanned downtime when a rapid drop-in swap is required to bring a machining center, turning cell or router back online with minimal disruption.

Control-duty contact capability covers AC-15 B300 and AC-15 C300 categories, with DC-13 at 24 V supported up to 4 A and 2 A depending on the channel. These ratings are well suited to switching control coils, enabling signals and feedback loops commonly found around CNC drives, PLC safety inputs and main contactors.

In machine-tool environments this model is often paired with door switches, emergency stops and safety relays in the same PREVENTA line, providing consistent terminal layout and straightforward panel documentation. Its use across many Schneider Electric panels makes it a practical spare part for mixed-fleet maintenance.

XPSAT5110 from TELEMECANIQUE in the PREVENTA XPS-AT series.

Supply options: 24 VAC or 24 VDC.

Control-duty capability: AC-15 B300 and AC-15 C300.

DC-13 at 24 V: up to 4 A and 2 A depending on channel.

Intended use: emergency stop chains, guard interlocks, light-curtain outputs and CNC safety loops.

Manufactured in France.

On the production floor this model is commonly installed as a drop-in replacement when an existing safety relay trips persistently, will not reset or shows coil faults. Keeping one in industrial spare inventory shortens troubleshooting time because wiring and terminal designation match established PREVENTA practice, allowing quick verification and restart.

For planned maintenance it fits well into preventive strategies on legacy CNCs still running Schneider Electric safety circuits. Many teams keep a sealed unit on the shelf to reduce changeover time during shutdowns and to secure machine uptime when a relay reaches end of life.

Units are functionally checked on dedicated safety relay benches and simulators by skilled engineers, then packed for industrial shipping with protective materials. Supplied with warranty and available with fast dispatch depending on availability, including worldwide delivery options.

This model can serve as an emergency spare when an older CNC panel relies on the PREVENTA XPS-AT line. Cnc-shopping can assist with sourcing obsolete parts, and repair or exchange service may be possible depending on the returned unit’s condition.

Frequently asked questions about XPSAT5110:

What supply voltage does the unit require?
It operates from either 24 VAC or 24 VDC, which makes it suitable for most CNC cabinets without modifying the control power supply.

How are the outputs rated?
Outputs are specified for AC-15 B300 and AC-15 C300 control duty, with DC-13 at 24 V up to 4 A and 2 A depending on the channel. Always verify against your panel drawings and contactor coil load.

Is it a direct field replacement for PREVENTA XPS-AT references?
Yes, it corresponds to the PREVENTA XPS-AT series and is used as a direct replacement when the cabinet was originally wired for this reference. Terminal layout and function align with the series design.

Where is it typically used in a CNC system?
Common placements include the E-stop chain, door switch monitoring and light-curtain output control, feeding the main contactor and drive enable circuits of machining centers and turning machines.

Does it require programming?
No programming is needed. Commissioning is performed through correct wiring and standard safety reset logic as defined by the machine schematic.
