SIEMENS 6FC5103-0AB03-0AA2 Sinumerik 840C/840CE Complete Operator Panel Color Display 9.5inch

Starting at €2,300.00 €2,300.00

Product condition Availability Warranty
Price
Refurbished
Ships from: FRANCE Warehouse
stock available Shipment within 3 days
4 months Warranty - Factory return he product is under warranty for a factory return to our workshop, to be repaired or replaced, throughout its warranty period.
€2,300.00 €2,300.00
Estimate Totals

Enter your destination to get a totals estimate.

  • Top-quality products backed by a warranty
  • Advanced technical support
  • Secure payment process with PDF invoice

Buy online your SIEMENS 6FC5103-0AB03-0AA2 Sinumerik 840C/840CE Complete Operator Panel Color Display 9.5inch reference 6FC5103-0AB03-0AA2 from our e-store Cnc-shopping, specialist in CNC machine-tools spare parts.

This SIEMENS front HMI for the SINUMERIK 840C/840CE control replaces the complete operator unit on legacy machine tools. It combines a 9.5 inch color display, full machine keyboard and two touch key strips, providing the primary user interface for programming, jogging and cycle operation. Ideal as a refurbished replacement unit or service spare part, it restores operator control on machines running the 840C or 840CE platform.

Delivered as a complete SLIMLINE panel, the 6FC5103-0AB03-0AA2 includes the SIEMENS 6FC5147-0AA14-0AA1 power supply module, the factory interface board and the full keypad set. The unit accepts 115 to 230 V AC input, which simplifies installation during field replacement on mixed-voltage cabinets. The integrated interface board links the operator panel to the 840C or 840CE control, so no separate HMI assembly is required when swapping a failed front panel.

Commonly used on vertical and horizontal machining centers, turning machines and grinders equipped with SINUMERIK 840C/840CE, this panel is a direct, panel-cutout compatible swap for the same reference. It is frequently sourced when the original display goes dark, keys become unresponsive, or the internal PSU fails. Alternate order markings often seen in the field include 6FC5103 0AB03 0AA2, 6FC51030AB030AA2, 6FC51O3-OABO3-OAA2 and PSU code 581 264 TA, which match this complete assembly.

Refurbishment focuses on dependable keypad response, clean signal integrity through the interface board and stable display output. This helps maintenance teams return the machine to service quickly without reworking wiring or reconfiguring the control.

Reference: 6FC5103-0AB03-0AA2

Manufacturer: SIEMENS

Product type: Operator panel for SINUMERIK 840C/840CE

Main function: Complete HMI with integrated 9.5 inch color screen, full keyboard and touch key strips for machine operation and programming

Applications: Machine tools running SINUMERIK 840C or 840CE controls on mills, lathes and grinders where a drop-in front panel replacement is required

Key technical data: SLIMLINE assembly, 9.5 inch color display, includes SIEMENS PSU 6FC5147-0AA14-0AA1 code 581 264 TA, integrated SIEMENS interface board, full keyboard with two touch key strips, 115-230 V AC supply range, refurbished and tested unit, functional warranty, typically ships within 3 days depending on availability, made in Germany. Also referenced as 6FC5103 0AB03 0AA2 and 6FC51030AB030AA2.

In day-to-day maintenance, this assembly is used to resolve no-display issues, dead keys and PSU faults on legacy 840C/840CE installations. Keeping one on the shelf as a stocked replacement unit reduces machine downtime during unplanned failures and supports preventive changeouts during planned overhauls or control refurbish work.

For retrofit or after a spill or impact on the original console, this complete front panel allows a clean field replacement with minimal cabinet work. It is a practical way to extend the service life of machines where the control remains stable but the HMI has aged.

Each refurbished panel is verified by skilled engineers on appropriate SINUMERIK 840C/840CE test benches and simulators. Visual inspection, keyboard response checks and power stability tests are performed before shipment. Units are packed in ESD-safe materials and prepared for industrial transport. Supplied with a functional warranty, with worldwide shipping options.

This model is often used as an emergency spare for older 840C/840CE systems where original HMIs are now an obsolete part. Cnc-shopping can support repair service or exchange service depending on condition, helping keep legacy machines available and productive with the right CNC replacement component.

Frequently asked questions about 6FC5103-0AB03-0AA2:

Is this panel a direct replacement for SINUMERIK 840C and 840CE controls?
Yes, it is designed for both 840C and 840CE installations and includes the required SIEMENS interface board for integration with these systems.

What power input is required?
The unit operates on a wide range 115-230 V AC input. Verify the cabinet wiring and protection before energizing the replacement unit.

Does it include the internal power supply and keyboard strips?
It comes complete with the 6FC5147-0AA14-0AA1 PSU, the interface board, the main keyboard and two touch key strips, ready for field replacement.

Which issues does this replacement typically solve?
It addresses failed or dim displays, non-responsive or damaged keys and power faults in the original HMI assembly on 840C/840CE machines.

Are alternate markings equivalent to this reference?
Markings such as 6FC5103 0AB03 0AA2, 6FC51030AB030AA2 and PSU code 581 264 TA are commonly associated with this complete operator panel.
