SIEMENS 1PH7105-2NF03-0CJ0 Motor

Buy online your SIEMENS 1PH7105-2NF03-0CJ0 Motor from our e-store Cnc-shopping. This high-performance motor is designed to meet the rigorous demands of modern industries and machine tools.

The SIEMENS 1PH7105-2NF03-0CJ0 SIMOTICS M compact asynchronous motor is a high-performance asynchronous motor designed to meet the demands of modern industrial applications. With a rated power of 7 kW at 1500 rpm and a torque of 44.6 Nm, it can achieve a maximum power of 8 kW at 1750 rpm with a torque of 43.7 Nm and a rated current of 17.5 A. Operating at 400V 3AC 50Hz, it is equipped with an integrated fan for optimal cooling and a precise relative motor encoder 1 VSS 2048 P/U.

Its design includes a terminal box positioned on the top, a cable outlet on the right, and a construction type IM B5 (IM V1, IM V3). It offers low vibration with a severity level S, shaft and flange accuracy of class R, and a smooth shaft without a fitted key. The airflow is directed from the drive end (DE) to the non-drive end (NDE). With a protection class of IP55 for the motor and IP54 for the fan, it is built to withstand demanding industrial conditions. The motor is unpainted, allowing customization as needed.

Ready to replace your defective motor, this product comes with a warranty, extending the lifetime of your machinery and reducing downtime.
