HEIDENHAIN UM116D Spindle drive Axis module 150A/300A - 210A/300A Id. 667954-01
Starting at €5,600.00 €5,600.00
Buy online your HEIDENHAIN UM116D Spindle drive Axis module 150A/300A - 210A/300A Id. 667954-01 reference UM116D from our e-store Cnc-shopping, specialist in CNC machine-tools spare parts.
This HEIDENHAIN power module is a spindle and axis drive unit used in TNC-controlled installations to command motion, manage current delivery and ensure stable operation of servo axes and spindle packages. It serves as a CNC replacement component for field failures or retrofit work and is commonly sourced as a replacement unit by maintenance teams looking to restore machine uptime without reengineering the control cabinet.
The UM116D integrates into HEIDENHAIN-driven cabinets where the TNC control supervises both axis and spindle channels. It regulates motor power while monitoring thermal and load conditions, helping keep position control stable under machining load. The design suits machining centers, milling lines, precision grinders and turning machines built around HEIDENHAIN motion control, where a reliable drive module is critical for rapid axis response and consistent spindle torque.
Rated groupings indicated on the front label support both axis and spindle assignments within the same module family, allowing the unit to serve mixed-drive cabinets when configured to the machine’s parameters. With current consumption 400 mA/220 mA on internal electronics and an integrated cooling fan unit, the drive maintains stable thermal behavior in enclosed electrical cabinets when cabinet airflow is properly maintained.
Typical losses are approximately 1115 W on the axis channel and 1560 W on the spindle channel, figures that help maintenance staff plan cabinet ventilation and service intervals. The module carries Id. 667954-01 for part matching, making it straightforward to verify against the machine’s drive list and nameplate during a planned swap or emergency changeout.
Reference: UM116D
Manufacturer: HEIDENHAIN
Product type: HEIDENHAIN TNC Controls - Digital Readout
Main function: Power and control module for HEIDENHAIN motion axes and spindle drive channels in TNC-based machines
Applications: Machining centers, milling machines, grinders and lathes using HEIDENHAIN TNC controls and HEIDENHAIN servo/spindle packages
Key technical data: Electronics consumption approx. 400 mA/220 mA; thermal dissipation about 1115 W axis and 1560 W spindle; integrated fan cooling; manufacturer Id. 667954-01; engineered in Germany; suitable as a replacement unit or refurbished unit depending on sourcing
In daily maintenance, the UM116D is used as a direct field replacement to recover machines from drive faults, overload trips or loss of spindle enable. Keeping one as a stocked spare reduces machine downtime and helps maintenance teams execute fast swap-and-test procedures during shifts or planned weekend outages.
For plants running legacy TNC controls, this unit supports long-term serviceability without altering the control strategy. It fits preventive maintenance plans where a known-good tested unit is verified on the bench before cabinet installation to minimize troubleshooting time and get the machine back in cut quickly.
Each drive is tested on CNC simulators with servo motors by skilled engineers to validate enable, command and feedback behavior. Units are packed for industrial transit with protective cushioning, and supplied with a warranty from Cnc-shopping. Fast dispatch is available depending on inventory, with worldwide shipping options suitable for urgent maintenance needs.
This part can serve as an emergency spare part to cut downtime during unexpected failures. Cnc-shopping can assist with obsolete part sourcing for HEIDENHAIN drives, along with exchange service and repair service options to keep older installations operational and extend machine life without a full control retrofit.
