main product photo

HEIDENHAIN RON 287C 18000 Pulses 03S12-03 Distance Coded

Rating:
100% of 100
2  Reviews

Starting at €2,000.00 €2,000.00

Manufacturer's Suggested Retail Price (10-2024): €6,250.00
Product condition Availability Warranty
Price
Refurbished
Ships from: FRANCE Warehouse
stock available Shipment within 3 days
4 months Warranty - Factory return he product is under warranty for a factory return to our workshop, to be repaired or replaced, throughout its warranty period.
€2,000.00 €2,000.00
Your savings on Manufacturer's suggested retail price: €4,250.00
New
Ships from: FRANCE Warehouse
stock unavailable Out of stock
12 months Warranty - Factory return he product is under warranty for a factory return to our workshop, to be repaired or replaced, throughout its warranty period.
€3,800.00 €3,800.00
Contact Us
Your savings on Manufacturer's suggested retail price: €2,450.00
  • High-quality products with warranty
  • Expert technical service
  • Secure payment and PDF invoice

Buy online your HEIDENHAIN RON287C 18000 03S12-03 Encoder available from our Cnc-shopping e-store. Cnc-shopping is offering you for sale a HEIDENHAIN encoder type RON 287C 18000 lines count to replace your defective or faulty rotary encoder. The HEIDENHAIN Id.Nr. of this encoder is HEIDENHAIN Id.Nr. 358701-05. Compact incremental angle encoder with integral bearing and integrated stator coupling for measuring steps to 0.0005° with 1Vpp Output. This Heidenhain pulse coder has 18000 lines count with 20mm hollow through shaft and integrated stator coupling: rugged design, typical applications include rotary tables, tilting tables, positioning spindles and synchronization monitoring. For measuring steps to 0.0001°. This encoder type HEIDENHAIN RON 287C 18000 comes with a warranty. Frequently mounted on HURON Machine for the 4th axis (table); These HEIDENHAIN Encoders are FULLY tested on HEIDENHAIN PWM dedicated Measurement equipments.

Output: 1Vpp (1vss)

Accuracy: ±2.5

Line count: 18 000

Power supply: 5VDC (±10%)

Shaft: Hollow through shaft for axial clamping and diameter of 20mm


HEIDENHAIN RON287 18000 angle encoders have an integral bearing, hollow shaft and integrated stator coupling. The measured shaft is directly connected with the shaft of the angle encoder. The reference mark can be assigned to a desired angular position of the measured shaft from the rear of the encoder during mounting.
More Information
AvailabilityShipment within 3 days
Voltage5DVC
Connector03S12-03
Resolution18000P
Pulse coder Signal1vpp
Shaft diameter20.000000
Weight3.00 kgs
HEIDENHAIN-RON287-DATASHEET-DRAWINGS-363470-94_1 (766.95 kB)
HEIDENHIAN-RON287C-BROCHURE_1 (171.27 kB)
