HEIDENHAIN ROD 350 500 ID 268050-01 Rotary encoder
Starting at €790.00 €790.00
Buy online a HEIDENHAIN ROD350 500 (ROD 350 500) Encoder for sale on Cnc-shopping website. This is a Heidenhain sealed angle encoder from the ROD350 series with 17mm tapered hollow shaft diameter dimensions with integrated bearing. The HEIDENHAIN ROD350 encoder photoelectrically scans pure binary patterns on a glass graduated disk to determine the position value. ROD350 has a resolution of 500 pulses/rev. This HEIDENHAIN ROD350 500 Pulses is usually installed on SIEMENS Motor.
Incremental rotary encoder with integral bearing for mounting by stator coupling
Line count:Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â 500
Output signal:                        11 µApp
Max. scanning frequency:Â Â Â Â Â 180.00 kHz
Power supply:Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â 5V+-10%
Coupling version:Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â mounting plate for wire clip
Shaft:Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â taper shaft 1:10, functional diameter 13.25mm
Degree of protection:Â Â Â Â Â Â Â Â Â Â Â Â Â IP 64 (EN 60529)
Operating temperature:         -40/+100 °C
| Availability | Shipment within 3 days |
|---|---|
| Resolution | 500P |
| Shaft diameter | 17.000000 |
| Weight | 3.00 kgs |
-
