FANUC A02B-0120-B513 Series 16-MA 6 Slot Backplane

Buy online your FANUC A02B-0120-B513 Series 16-MA 6 Slot Backplane from our UK e-store Cnc-shopping UK, specialist in CNC machine-tools spare parts.

The FANUC A02B-0120-B513 is a 6-slot backplane board designed for the FANUC Series 16-MA CNC control system. It serves as the passive backbone of the master rack, interconnecting the CPU, axis control, spindle control, memory, and I/O interface boards while distributing the required DC power throughout the system. This backplane plays a critical role in maintaining reliable communication between modules and ensuring stable operation of machining centers and CNC milling machines equipped with FANUC 16-MA controls.

Designed for the main control rack, the A02B-0120-B513 accommodates up to six plug-in modules and carries the Series 16 system bus signals between them. Typical rack configurations include the main CPU board, SRAM and memory modules, axis control boards, I/O interfaces, and spindle control hardware. Proper slot allocation, grounding, and power distribution are essential for reliable system startup, axis enable functions, and alarm-free machine operation.

This backplane is commonly found in machining centers and vertical mills originally built with FANUC 16-MA controls. It is frequently replaced when machines experience intermittent resets, communication errors, bus faults, or startup problems caused by aging connectors, damaged traces, or degraded backplane connections. Because it supports the reuse of existing A16B and A20B series plug-in boards, it allows maintenance teams to retain machine parameters and system configuration while restoring hardware reliability.

Installed inside the FANUC control cabinet, the A20B-1004-0580 provides the system bus connections required for the operation of the CNC. It acts as the backbone of the control rack, ensuring that all installed modules can exchange data and receive the necessary DC power from the associated FANUC power supply. Reliable backplane communication is essential for machine startup, axis control, spindle operation, and I/O processing.

Manufactured in Japan to FANUC industrial standards, the A02B-0120-B513 is an important spare part for maintaining legacy FANUC 16-MA installations. Many maintenance departments keep a replacement unit in stock to minimize downtime and support rapid field repairs without disturbing the existing board configuration.

Each unit can be inspected and tested on appropriate CNC test benches to verify bus continuity, connector condition, and overall functionality before shipment. Depending on availability, the backplane may be supplied as a tested or refurbished unit. Repair and exchange services may also be available to help extend the service life of FANUC 16-MA systems, which are now considered legacy platforms with increasingly limited OEM spare-part availability.

Frequently asked questions about A02B-0120-B513:

Which FANUC control does this backplane support
It is designed for the FANUC Series 16-MA control and fits the corresponding master rack and power supply assembly from that generation.

How many boards can be installed
The backplane provides six slots for plug-in modules such as CPU, memory, axis control, I/O interface and spindle control boards used on 16-MA systems.

Can I reuse my existing 16-MA boards after replacing the backplane
Yes, technicians usually move the original plug-in boards to the replacement backplane, then power up and verify bus communication and alarms. Back up parameters before any hardware work.

Does it include the rack or power supply
This listing covers the backplane only unless otherwise stated. The card cage, mounting hardware and the matching FANUC power supply are handled as separate items.

Is this suitable as a field replacement during downtime
Yes, it is commonly sourced as a spare part for urgent replacements. Fast dispatch is possible depending on inventory, with worldwide shipping available.
