B&R AUTOMATION ACOPOS 1090 8V1090.00-2 Servo Drive 8.8A 4kW - AC114 Version Certified

Starting at €1,800.00 €1,800.00

Product condition Availability Warranty
Price
Refurbished
Ships from: FRANCE Warehouse
stock available Immediate shipment Estimate my delivery
4 months Warranty - Factory return he product is under warranty for a factory return to our workshop, to be repaired or replaced, throughout its warranty period.
€1,800.00 €1,800.00
Estimate Totals

Enter your destination to get a totals estimate.

  • Top-quality products backed by a warranty
  • Advanced technical support
  • Secure payment process with PDF invoice

Buy online your B&R AUTOMATION ACOPOS 1090 8V1090.00-2 Servo Drive 8.8A 4kW - AC114 VERSION CERTIFIED reference 8V1090.00-2 AC114 Approved from our e-store Cnc-shopping, specialist in CNC machine-tools spare parts.

This B&R ACOPOS 1090 servo drive is a power module for precise axis control in CNC and industrial automation. It supplies regulated power to B&R servo motors, manages braking energy internally and interfaces to fieldbus and encoder feedback through front plug-in cards. Commonly sourced as a replacement unit or spare part for motion axes on machine tools and automated equipment, it helps restore machine uptime quickly.

The module identified as 8V1090.00-2-AC114 is the basic unit of the ACOPOS 1090 line with an integrated line filter and an integrated braking resistor. It operates on 3 x 400-480 V mains, supports up to 8.8 A output current and is suited for axes up to 4 kW. These built-in components reduce external hardware, simplify panel design and shorten replacement time in the field.

The AC114 version certified variant maintains rated performance up to 45 C ambient inside the cabinet. This is relevant on production floors where cabinets run warm, because it allows the drive to deliver its nominal ratings within the specified temperature window without derating.

Front plug-in compatibility enables flexible integration. Supported options include 8AC110.60-2 for CAN networking, 8AC120.60-1 for EnDat feedback, 8AC122.60-1 for resolver feedback, 8AC123.60-1 for incremental and SSI absolute encoders, and 8AC130.60-1 for digital I/O. When replacing a failed unit, the existing interface card set is typically transferred to the new drive to match the machine configuration.

In CNC and general automation cabinets using B&R motion, this drive is installed as a cabinet-mounted axis module supplying the motor with regulated current while managing regenerative energy through the built-in brake resistor. It is commonly used on feed axes, auxiliary handling axes and retrofit projects where a direct CNC replacement component is required without redesigning the control panel.

8V1090.00-2-AC114 in the B&R ACOPOS 1090 family, designed for servo axis control on B&R motion systems.

Rated for 3 x 400-480 V mains with nominal 8.8 A output to the motor and up to 4 kW axis power.

Equipped with an integrated line filter and integrated braking resistor to streamline cabinet wiring and reduce external parts.

Supplied as AC114 version certified, this module supports AC114 Interface module (8AC114 communication board)

Accepts ACOPOS plug-in cards: 8AC110.60-2 CAN, 8AC114 PowerLink V2, 8AC120.60-1 EnDat, 8AC122.60-1 resolver, 8AC123.60-1 incremental and SSI, 8AC130.60-1 digital I/O.

Used as a replacement unit, tested unit or refurbished unit depending on sourcing, with options for repair service or exchange service on request.

On the production floor this model is selected to minimize machine downtime when a drive trips on overcurrent, fieldbus faults or internal errors. Technicians can move the original front plug-in cards to the new module, reload parameters and bring the axis back online with minimal wiring changes. Many maintenance teams keep a stocked spare to support planned shutdowns and preventive replacements on aging lines.

Each drive can be functionally checked on CNC simulators with servo motors by skilled engineers, including feedback and fieldbus verification when applicable. Units are packed with ESD-safe materials and protected for industrial transport, supplied with a warranty. Fast dispatch is possible depending on availability with worldwide shipping options.

This item is suitable as an emergency spare for B&R-based motion systems and is often used to keep older installations running when originals become an obsolete part. Cnc-shopping can assist with sourcing hard-to-find ACOPOS modules, as well as organized repair service or exchange service to reduce unplanned downtime and extend machine life.

Frequently asked questions about 8V1090.00-2 AC114 Certified version:

Is this a direct substitute for an ACOPOS 1090 8V1090.00-2 module?
Yes, it is the same basic unit in the ACOPOS 1090 line as the AC114 certified version (Guaranteed to function with 8AC114 interface module). It installs in the same location and normally reuses the existing front plug-in cards and wiring.

Which feedback encoders can be connected?
Supported feedback depends on the front card installed. Options include EnDat with 8AC120.60-1, resolver with 8AC122.60-1, and incremental or SSI absolute with 8AC123.60-1.

What mains voltage and power rating does it support?
The unit runs on 3 x 400-480 V and is intended for axes up to 4 kW with a nominal motor output current of 8.8 A.

Does it include line filtering and a brake resistor?
Yes, both the line filter and the braking resistor are integrated, which helps reduce external components and speeds up field replacement.

What cabinet temperature can it handle at full rating?
Rated operation is maintained up to 45 C ambient inside the electrical enclosure as specified for the AC114 certified version.

More Information
AvailabilityImmediate shipment
Weight7.00 kgs
