A86L-0001-0155#A Fanuc 15 Keyboard

Be the first to review this product

Starting at €300.00 €300.00

Manufacturer's Suggested Retail Price €1.00
Product condition Availability Warranty
Price
Refurbished
Ships from: FRANCE Warehouse
stock available Immediate shipment Estimate my delivery
2 months Warranty - Factory return he product is under warranty for a factory return to our workshop, to be repaired or replaced, throughout its warranty period.
€300.00 €300.00
Your savings on Manufacturer's suggested retail price: -€299.00
Estimate my delivery

Enter your destination to get a shipping estimate.

  • High-quality products with warranty
  • Expert technical service
  • Secure payment and PDF invoice

FANUC 53 Keys keyboard from FANUC 15 CNC CRT/MDI Panel. Keyboard reference FANUC A86L-0001-0155#A for sale online to replace a defective Fanuc keyboard or keyboard with damaged keys. This FANUC A86L-0001-0155#A keyboard is tested and comes with a warranty. Reference FUJITSU N86D-3161-R001/02 N860-3161-T001

How to replace your Fanuc 15 Keyboard ?

1.The small printed circuit board at the rear of the MDI keyboard can be seen from the back of the CRT/MDI control unit. There is a flat cable, coming from the soft keyboard, attached to this printed circuit board.
Disconnect this cable.
2 Remove the cable attached to the power on/off button.
3 Remove the M3 screws from the front panel attached to the sheet metal panel of the CRT/MDI unit.
4 The keyboard is located in between the front panel and the sheet metal panel. The keyboard can now be removed (there are no screws holding the keyboard).
5 Insert the new keyboard into the front panel. Screw the front panel onto the sheet metal panel.
6 Reattach the power on/off cable and flat cable removed in steps (1) and (2) to their original positions.
