A06B-6100-H001 Fanuc RJ3 Robot 6axis drive
Starting at €3,500.00 €3,500.00
Buy online your A06B-6100-H001 Fanuc RJ3 Robot 6axis drive reference A06B-6100-H001 from our e-store Cnc-shopping, specialist in CNC machine-tools spare parts.
This FANUC 6-axis servo amplifier is designed for RJ3 robot installations and manages current control for joints J1 through J6. It receives fiber-optic commands from the robot controller and regulates torque and speed of the axis servo motors with closed-loop feedback. Commonly sourced as a replacement unit for FANUC S-430iF, S-430iR/130 and M-710i robots, it fits maintenance, retrofit and field repair needs where reliability and consistent axis performance are required.
Within the robot system this amplifier links the controller to the motor power stage through an optical fiber interface, providing noise-immune signaling in factory environments. The unit integrates the A20B-2003-0131 power board and the A16B-2100-0200 control board as a matched assembly, which is important for stable operation and alarm-free commissioning after a swap. Using the correct module preserves axis tuning managed by the RJ3 controller and helps keep motion behavior consistent across joints.
Technicians typically use this module during field replacement of faulty amplifiers showing overcurrent alarms, DC link faults or fiber link errors. Its construction and signaling match the RJ3 generation and the listed robot models, so cabling, mounting and controller interface remain straightforward during a drop-in change. For plants supporting mixed robot fleets, keeping this exact reference simplifies MRO stocking and reduces troubleshooting time during unplanned stops.
Where robots run long shifts, maintaining a like-for-like amplifier helps protect gearboxes and servo motors from unstable torque delivery. The included control and power boards ensure the unit arrives functionally complete, avoiding the need to transplant internal boards from a failed drive. That detail is useful when arranging a refurbished unit exchange or a rapid repair service turnaround.
Reference: A06B-6100-H001
Manufacturer: FANUC
Product type: FANUC Servo Drive A06B-6100 amplifier series
Main function: Six-axis servo amplification for RJ3 robots with fiber-optic command interface and closed-loop current control to the axis motors.
Applications: FANUC robot cells using RJ3 controllers, notably S-430iF, S-430iR/130 and M-710i models for assembly, handling and welding duties.
Key technical data: Complete 6-axis amplifier assembly including A20B-2003-0131 power stage and A16B-2100-0200 control board, fiber-optic interface to the robot controller, manufactured in Japan, supplied as a replacement spare part for RJ3-era robots. Listed with fast dispatch options and backed by warranty. Internal board references may include A20B-2002-0711 depending on revision.
In daily maintenance, this module is selected to restore robot motion after a drive failure without retuning axes, since tuning parameters are handled in the controller. Keeping a stocked spare reduces recovery time when an axis channel trips on hard faults. For scheduled overhauls it can be installed during gearbox or motor changes to return the robot to service with minimal retest time.
Each drive can be supplied as a tested unit. Our engineers verify operation on dedicated robot and CNC simulators with paired servo motors, checking fiber link communication, channel enable, current regulation and alarm reporting. Units are packed in robust industrial packaging and shipped with static protection. Warranty support is included as stated for this reference.
This module is often used as an emergency spare for RJ3 robots and is suitable for obsolete part coverage when original stock is scarce. Cnc-shopping can assist with exchange service or repair service to extend the lifetime of older FANUC installations and maintain uptime on legacy equipment.
Frequently asked questions about A06B-6100-H001:
Which robot models is this drive commonly used with?
It is used with RJ3-based robots including S-430iF, S-430iR/130 and M-710i. If your robot is RJ3 and originally shipped with this reference, it is typically a direct swap.
Does it include the internal boards or are they separate?
This assembly comes complete with the A20B-2003-0131 power board and the A16B-2100-0200 control board, so no board transplant from the failed unit is required.
What communication interface does it use to the controller?
The amplifier uses an optical fiber interface for command and feedback exchange with the RJ3 controller, providing noise immunity in industrial environments.
Are robot parameters stored in the amplifier?
Axis parameters and motion data are managed by the robot controller. When replacing the amplifier with the same reference, no parameter write to the drive is typically needed.
Can this be supplied as a refurbished unit with testing?
Yes, units can be provided as refurbished or exchange options and are tested on simulators with servo motors by experienced engineers before dispatch.
